Hydraulic guillotine shearing machine 3200mm x 8mm with pneumatic material support

• Real Innovation,
• High Quality, High Performance and Good Price,
• User Friendly Control Unit,
• Monoblock, Steel Welded Construction,
• High Precious Cuttings,

Standards:

- ‪#Variable rake design
- ‪#Germany ELGO P40 NC Controller
- Motorized blade gap adjustment
- 750mm powered ball screw back gauge
- 130mm throat depth with side guards
- Adjustable stroke length & digital counter
- Powerful material holddowns
- Front squaring arm with scale & support arms
- Front finger guards
- Cutting line illumination
- Ball transfer table and T-slots

Hydraulic Shearing Machine Features include:

•Solid monolithic structure
•An avant-garde hydraulic system
•Blade carrier beam: Thrust cylinders on the cutting axis with blade carrying beam
•Blade pressure cylinders, with auto-regulating pressure, based on cutting force
•Blade carrying beam guide over the whole cutting length
•Rear regulator with recirculating ball screws
•Running wheels’ table and frontal support
•Cutting Angle & Blade Gap by P40 control
•Cutting line with LED illumination
•Germany ELGO P40 NC control System
•Frontal support frame complete with retractable adjustable guides, millimetre rule and running wheels
•HIWIN Ball screws & Polished rod with 0,01 mm accuracy.

Quick Details

Condition: New
Place of Origin: Anhui, China (Mainland)
Brand Name: Accurl
Model Number: MS8-8x3200 Hydraulic Guillotine
Voltage: 380V/60HZ or 220V/60HZ
Rated Power: 22KW
Dimension(L*W*H): 3945x2127x2235mm
Weight: 7200Kgs
Certification: CE,UL and ISO
Warranty: Two year free warranty under proper use after installation,
After-sales Service Provided: Engineers available to service machinery overseas
NC Control system: GERMANY ELGO P40 CNC CONTROL UNIT
Mild Steel (450Mpa): 8mm
Max. Cutting Length: 3200mm
Main motor: Siemens from Germany Brand
Strength of sheared plate: 450 N/mm2
BackGauge & RAM Drive: Inverter from Taiwan delta
Hydraulic System: Bosch-Rexroth form Germany
Ball screw/ Polished rod: HIWIN from TaiWan Brand
Electrical components: Schneider Electrical from French
Working voltage: 380V (-15%,+15%),60Hz,3PH
