WC67K servo electric press brake,hydraulic bending machine,servo cnc metal bending machine

estun control system press brake

Product Description

1.Special numeric-control system is fitted with mainframe of brake press .

2. Multi-work-step programming function is able to achieve an automatic operation and continuous positioning of multi-step procures, as well as an automatic precision adjustment for positions of rear stopper and gliding block.

3. The machine is provided with bend counting function, for a real-time display of processing quantity and power failure memory of positions of stopper and gliding block, as well as procedures and parameters.

4. Imported ball bearing lead screw and linear guide rail are used for rear stopper, to ensure the positioning precision of rear stopper, for processing precision of machine to be higher.

Technical Specification for brake press

Model	Pressure	Bending	Columns	Open	Throat	Slide	Motor	Machine
Model	KN	Leng (mm)	Distance (mm)	Height (mm)	Depth (mm)	Stroke (mm)	Power (kw)	Size (mm)
40T/2500	400	2500	1850	210	200	110	4	2500x1200x1910
63T/2500	630	2500	2000	235	250	120	5.5	2500x1320x2210
63T/3200	630	3200	2600	235	250	120	5.5	3200x1300x2210
80T/2500	800	2500	2000	320	320	150	7.5	2600x1400x2380
80T/3200	800	3200	2600	320	320	150	7.5	3300x1400x2380
80T/4000	800	4000	3100	320	320	150	7.5	4100x1400x2380
100T/2500	1000	2500	2000	330	320	150	7.5	2600x1400x2380
100T/3200	1000	3200	2600	330	320	150	7.5	3300x1400x2380
100T/4000	1000	4000	3100	330	320	150	7.5	4100x1400x2380
125T/2500	1250	2500	1900	330	320	150	7.5	2600x1400x2380
125T/3200	1250	3200	2600	330	320	150	7.5	3300x1400x2380
125T/4000	1250	4000	3100	330	320	150	7.5	4100x1400x2380
125T/5000	1250	5000	4100	330	320	150	7.5	5100x1400x2380
160T/2500	1600	2500	1900	400	320	200	11	2600x1550x2580
160T/3200	1600	3200	2600	400	320	200	11	3300x1550x2580
160T/4000	1600	4000	3100	400	320	200	11	4100x1550x2580
160T/5000	1600	5000	4100	400	320	200	11	5100x1550x2580
160T/6000	1600	6000	4800	400	320	200	11	6100x1550x2580
200T/2500	2000	2500	1900	435	320	200	15	2600x1650x2900
200T/3200	2000	3200	2600	435	320	200	15	3300x1650x2900
200T/4000	2000	4000	3100	435	320	200	15	4100x1650x2900
200T/5000	2000	5000	4100	435	320	200	15	5100x1650x2900
200T/6000	2000	6000	4800	435	320	200	15	6100x1650x2900
250T/2500	2500	2500	1900	435	320	200	18.5	2600x1750x3070
250T/3200	2500	3200	2600	435	320	200	18.5	3300x1750x3070

Our Services

1.Your inquiry will be replied in 24 hours for brake press .
2. Professional manufacturer ,there is more industry technology experience for 18 years with our products
3.To offer free spare parts and service within 24 month of warranty
4.Technology Support Provide operation video for training
5.Professional after-sales service team for brake press .

Quick Details

Condition: New
Place of Origin: Anhui, China (Mainland)
Brand Name: ACCURL
Model Number: WC67K/Y
Machine Type: Press Brake
Raw Material: Sheet / Plate Rolling
Material / Metal Processed: Carbon Steel
Power: Hydraulic
Automation: Automatic
Extra Services: Machining
Certification: ISO 9001:2000, ISO9001
After-sales Service Provided: Engineers available to service machinery overseas
Type: Press bending brake
maintenance: 5 years
Main Motor: Siemens
Control system: Estun
hydraulic system: Bosch rexroth
Major Low voltage electrical: Schneider
Seal ring: Valqua
Ball screw ,Linear guide: HIWIN for press brake
Color: Optional
